9 Technical Data

9.1 Technical Specifications

The technical information provided hereafter applies to a standard configuration or represents maximum achievable values.
These can change if accessories are added. The precise changes to these values are detailed in the sections for the respective
accessories.
Note that in some cases the measured values may vary up to ± 10 mm.
For more technical data of the power wheelchair see the user manual of your wheelchair.
Dimensions Modulite Seating System
Dimensions According to ISO 7176-15
Seat Width (Armrest Adjustment Range in
Parentheses)
Seat Depth
Seat Cushion Thickness
Backrest Height 1
Backrest Angle
1656515-B
Power Wheelchair
TDX SP2
• 380 mm (380 - 430 mm)
• 430 mm (430 - 480 mm)
• 480 mm (480 - 530 mm)
• 530 mm (530 - 580 mm)
• 410 - 560 mm
• 50/ 75/ 90/ 100 mm
• 480/ 540 mm (sling back)
• 560 - 660 mm (telescopic seat
frame, moving the backrest plate)
• 90° - 120°
AVIVA RX
• 330 mm (330 - 380 mm)
• 380 mm (380 - 430 mm)
• 430 mm (430 - 480 mm)
• 480 mm (480 - 530 mm)
• 530 mm (530 - 580 mm)
• 410 – 510 mm
• 480/ 540 mm (sling back)
• 560 - 660 mm (telescopic seat
frame, moving the backrest plate)
• 400/ 500 mm (Matrix back)
Technical Data
