Invacare® Modulite
Drive Slowdown
Seating systems are configured/programmed with a drive
slowdown. The drive slowdown utilises microswitches to
trigger the system into reduced drive speed.
Fig. 3-4 Home position (left), drive slowdown due to height (right)
Fig. 3-5 Drive slowdown due to backrest angle
10
Wheelchair Height
Model
AVIVA RX • >50 mm
Drive Lockout (DLO) Limit
All tilt and recline seating systems are equipped with a drive
lockout (DLO) limit to prevent the wheelchair from being
driven when the seating system is tilted or reclined beyond
a pre-determined safe total angle and/or a pre-determined
height. The total angle can be any combination of seat
angle, backrest angle and/or surface angle.
Wheelchair Height
Model
AVIVA RX • >50 mm
Backrest Angle
• <130°
Backrest Angle
• >130°
