Table 6-33 Example BIOS Messages (continued)
Message
Shadow RAM Failed at
offset: nnnn
nnnn Shadow RAM
Passed
Software NMI Failed
System battery is dead -
Replace and run SETUP
System BIOS shadowed
System cache error -
Cache disabled
System CMOS checksum
bad - run SETUP
System RAM Failed at
offset: nnnn
nnnn System RAM
Passed
System timer error
UMB upper limit segment
address: nnnn
Video BIOS shadowed
PrAMC-7311 Installation and Use (6806800P34F)
Explanation
Shadow RAM failed at offset nnnn of the
64k block at which error was detected.
nnnn is amount of shadow RAM in KBs
successfully tested
ServerBIOS2 test error: Cannot generate
software NMI
The NVRAM (CMOS) clock battery
indicator shows the battery is dead
System BIOS copied to shadow RAM
RAM cache failed BIOS test. BIOS
disabled cache
System NVRAM (CMOS) has been
corrupted or modified incorrectly,
perhaps by an application program that
changes data stored in NVRAM (CMOS).
System RAM failed at offset nnnn in the
64k block at which the error was
detected.
nnnn is amount of system RAM in KBs
successfully tested
Timer test failed
Address nnnn of the upper limit of upper
memory blocks indicates released
segments of BIOS which may be
reclaimed by a virtual memory manager
Video BIOS successfully copied to
shadow RAM
BIOS Messages
Corrective Action
Contact your local sales
representative or services for
further support.
None
None
Replace battery and run
Setup to reconfigure system.
None
Contact your local sales
representative or services for
further support.
Run setup and reconfigure
system either by getting
default values and/or making
your own selections.
Contact your local sales
representative or services for
further support.
None
Requires repair of system
blade
None
None
