Figure 6-34 Boot Menu - SMART Embedded Computing PrAMC-7311 Installation And Use Manual

Boot Menu
The Boot Device Priority options are displayed in
2. Select the order of the devices from which BIOS attempts to boot the operating system.
In the next figure, the first boot device is SATA drive 1. BIOS attempts to boot from
the SATA drive 1. If BIOS fails to boot from this device, then BIOS attempts to load
the operating system from the SATA drive 2, trying options in ascending order, with
highest boot priority being number 1.
3. Select IBA GE Slot 0200 v1245 or IBA GE Slot 0201 v1245 to do a PXE boot through
the corresponding Ethernet port, for example ETH0 or ETH1 respectively.
Figure 6-34
To Change a Device's Priority
Follow these steps to change priorities of the boot device.
1. Select the device using the up or down arrow keys.
2. Use <x> to include or exclude the boot devices.
3. Use the [+] or [-] keys to move the priority up or down.
4. Press <Esc> to exit to the Exit Menu.
94
Boot Menu
Figure 6-34.
PrAMC-7311 Installation and Use (6806800P34F)
Basic Input Output System
