Thermal Configuration
The following figure shows the Platform Thermal Configuration submenu.
Figure 6-28

Table 6-28 Platform Thermal Configuration

Feature
Critical Trip Point
Active Trip Point Hi Fan
Active Trip Point Lo Fan
Passive Trip Point
Passive TC1 Value
Passive TC2 Value
Passive TSP Value
Pch Thermal Device
Thermal Sensor Device
Enable
88
Platform Thermal Configuration
Options Description
Allows to control the temperature of the ACPI critical trip
point - the point where the OS shuts the system off.
o
NOTE: 100 C is the Plan of Record (POR) for all the Intel
mobile processors.
Allows to control thermal sensor device.
