2.3.2

Thermal Requirements

The minimum airflow requirements for the AdvancedTCA platforms are 13CFM for the
2.2GHz PrAMC-7311 module platforms. This is with a maximum operating temperature
limit of 55°C (131°F).
Contact your SMART EC sales representative for current information on the detailed
thermal information including airflow and resistance of the PrAMC-7311.
2.3.3

Power Requirements

Make sure that the module is used on an approved AdvancedTCA carrier board in an
AdvancedTCA shelf connected to -48VDC up to -60VDC, for use in a restricted access area
only by trained personnel. All circuits are safety-extra-low-voltage (SELV) under normal
operating conditions, and are not subject to over voltages/transients.
Table 2-2
Feature
Rated voltage
Operating voltage
Input current
Power dissipation
The module provides two independent power inputs according to the AdvancedTCA
specification.
2.4

Module Installation and Removal

This section describes how to install and remove an AMC module.
Damage of Circuits
Electrostatic discharge and incorrect product installation and removal can damage
circuits or shorten their life.
Before touching the product or electronic components, make sure that you are
working in an ESD-safe environment.
PrAMC-7311 Installation and Use (6806800P34F)
DC System Power Requirements
Value
12VDC
10VDC to 14VDC
5A at 12V
30W (Typical)
60W (max)
Thermal Requirements
