Removal Procedure
Data Loss
Removing the blade with the blue LED still blinking causes data loss.
Wait until the blue LED is permanently illuminated, before removing the blade.
Poor Shelf Cooling and EMC Compliance Violation
An empty AMC bay may result in poor shelf cooling and strong EMC radiation and
thus lead to EMC compliance violation.
Always cover empty or unused AMC bays with a filler panel.
This procedure describes how to remove an AMC module from the base board. The
procedure assumes that the base board is powered. If it is not powered the steps regarding
the blue LED can be ignored and skipped.
1. Make sure you are in an ESD safe environment.
2. Remove any cables that are connected to the AMC module face plate connectors.
3. Gently pull the module latch outward, approximately 3mm from its locked position.
4. Wait for the blue LED to first perform short blinks, and then glow persistently.
5. Once the blue LED glows persistently, gently pull the AMC module handle outward to
disconnect the module from the AMC connectors. Continue to gently slide the module
outward along the guide rails.
6. Install an AMC filler panel.
