HDD Configuration

6.7.7 HDD Configuration
The following figure shows the HDD Configuration Options submenu.
Figure 6-11
The following table provides options in the HDD Configuration menu and their defaults.
Values contained in brackets [...] show the default setting.
Table 6-11
Feature
SATA Device
Interface Combination
Aggressive Link Power
Software Feature Mask
Configuration
Serial ATA Port 0
Serial ATA Port 1
70
HDD Configuration Menu
HDD Configuration Menu
Options Description
Allows to control SATA device.
Specifies the SATA controllers operation mode.
PrAMC-7311 Installation and Use (6806800P34F)
Basic Input Output System
