6.7.18

LPC Configuration

Figure 6-23
The following table provides options in the LPC Configuration menu and their defaults.
Values contained in brackets [...] show the default setting.

Table 6-23 South Bridge USB Configuration

Feature
On-board UART1
On-board CIR (UART2)
PrAMC-7311 Installation and Use (6806800P34F)
LPC Configuration
Options
LPC Configuration
Description
Allows to control the On-board UART1 address. If
enabled, UART1 uses address 0x3F8h and IRQ 4.
83
