Features
It is available as a mid-size AMC module.
Table 1-1
Feature
Processor
Memory
Quad Gigabit Ethernet
(SerDes)
1 Gbit Fast Ethernet
USB 2.0 Based SD
card
PCIe Interface
SATA Interface
RS-232 Port
Core Chip
MMC
Form Factor
28
Features
Description
Intel Core i7-2655LE LV processor (4 MB L3 cache) 2.2GHz
Support for dual channel DDR3-1333 registered memory and for 2Gbit
/ 4Gbit SDRAMs for 4GB / 8GB capacity, 4Gbit dual -die SDRAMS for
16GB capacity
Intel i350-AM4 (PCIe x 4) Dual 1Gbit SerDes interface via AMC fabric I/O
interface, Supports PXE boot
Intel i350-AM4 (PCIe x4)
Face plate RJ-45 port
Supports PXE boot
Optional 2GB MicroSD card
One PCIe x8 interface
Configurable as two PCIe x4 interfaces
Supported via AMC fabric I/O interface
Two Gen 2 SATA channels via AMC fabric I/O interface
Face plate RJ-45 port
Intel BD82QM67 Platform Controller Hub (PCH)
Renesas H8S/2472 microcontroller
Implementing Pigeon Point MMC firmware
Single width mid-size AMC (73.5mm x 181.5mm)
