LEDs

3.3.2 LEDs
Face Plate on page 38
The meaning of the LEDs is described in the following table.
Table 3-1
Name Color
OOS Red
IS Green
HS Blue
ACT
Green
type
Link
Yellow
status
40
shows the LEDs on the face plate.
Face Plate LEDs
Description
Out Of Service
This LED is controlled by higher layer software, such as middleware or
applications.
The IPMC turns this LED on when the payload gets activated and turns
it off when the payload gets de-activated.
In Service
This LED is controlled by higher layer software, such as middleware or
applications.
The IPMC turns this LED off when the payload gets either activated or
de-activated.
FRU State Machine
During module installation:
Permanently blue: On-board IPMC powers up.
Blinking blue: Module communicates with shelf manager.
OFF: Module is active.
During module removal:
Blinking blue: Module notifies shelf manager of its desire to deactivate.
Permanently blue: Module is ready to be extracted.
ACTIVITY type
Blinking: When Packets are Txed/Rxed
Off: No Activity
Link status
On: Link
Off: No Link
