Controls, LEDs, and Connectors

3.1

Overview

This chapter describes the face plate connectors and face plate LEDs.
3.2

Face Plate Connectors and LEDs

The following figure shows the face plate of the RTM-ATCA-F140.

Figure 3-1 Face Plate

ETH1, ETH2
Base 10G SFP+ Slots
ETH3-ETH6
Fabric 10G SFP+
Slots
ETH7 Fabric
40G QSFP+Slot
ETH8-ETH11
Base 1G SFP
Slots
Time-Of-Day
Input
RTM-ATCA-F140 Series Installation and Use (6806800M97M)
ETH1
ETH2
Out of Service LED
In Service LED
ETH3
I
S
Attention LED
A
T
N
ETH4
ETH5
ETH6
1PPS Input
1 PPS
ETH7
10MHz Input
10MHz
ETH8
ETH9
ETH10
ETH11
Hot Swap
LED
H
/
S
TOD
ARTM-F140
