Planmeca ProOne Technical Manual page 13

USER'S STATEMENT
Anode heating/cooling curve of the X-ray tube
Single load rating of the X-ray tube
Target material of the X-ray tube
Tungsten anode
Reference axis to which the target angle and the focal spot characteristics of
the X-ray tube refer
90° with respect to the anode-cathode axis (pan)
Target angle with respect to the reference axis
12.5°
Technical Manual
14
12
10
8
HEATING
6
4
2
0
0 1
16
50kV
14
60kV
12
70kV
10
8
6
4
2
0
0.1
EXPOSURE TIME (s)
GENERAL & TECHNICAL DATA
300W
200W
100W
COOLING
2 3 4
TIME (min)
1
CHAPTER A
5
10
Planmeca ProOne A-9
