Specifications

Capacities System
4 outside lines via line jacks on
two 206 modules or one 206 and
one 200 combination
12 extensions via extension jacks
on two 206 modules
1 Music On Hold device via Music 2 outside lines
On Hold coupler to ext. jack 15
10 special application phones via
10 ext. jacks
Dimensions
206 module
and Weights
200 module
(approx.) Two modules
MLS-18D phone
MLS-12D phone
MLS-12 phone
MLS-6 phone
MLC-6 phone
Switch Fabric Full digital, nonblocking
Electrical
1 Amp per 206 module; .25 Amp per 200 module
Specifications
On a PARTNER 220V System: 0.6 Amp per 206 module; .25 Amp per 200 module
65 Watts per 206 module; 10 Watts per 200 module
Dissipation of power: 30W/206 module and 20W/200 module during normal operation
225 BTUs/hour per 206 module; 35 BTUs per 200 module
4-day memory backup (96 hours)
Extension Ringing voltage: +5VDC, -140 VDC peak to peak; trapezoidal wave shaping
On a PARTNER 220V System: +5VDC, -150 VDC peak to peak
Jack
Specifications
35- to 38-Volt talk battery
Ringing frequency: 20 Hz
Proc. Module
80C321 microcontroller with 8K RAM and 64K ROM
Specifications
Music on
Electrical interfaces: one 657 jack to extension port one RCA phono jack to audio source
Hold Coupler 600 Ohm input on RCA jack ranging from 1mV to 4V
Specifications
*
The two devices combined on an extension jack can be a system phone with a standard device, or two standard devices; DO NOT
connect two system phones to the same extension jack. If a device lists two RENs, use the higher number when adding up RENs.
206 Module
2 outside lines
6 extensions
200 Module
11"(D) x 17"(H) x 1.5"(W) or 27.9 x 43.2 x 3.8 cm
11"(D) x 17"(H) x 1.5"(W) or 27.9 x 43.2 x 3.8 cm
12"(D) x 17"(H) x 5"(W) or 30.0 x 43.2 x 12.7 cm
9.5"(D) x 5"(H) x 6.75"(W) or 24.1 x 12.7 x 17.1 cm
9.5"(D) x 5"(H) x 6.75"(W) or 24.1 x 12.7 x 17.1 cm
9.5"(D) x 5"(H) x 6.75"(W) or 24.1 x 12.7 x 17.1 cm
9.5"(D) x 5"(H) x 6.75"(W) or 24.1 x 12.7 x 17.1 cm
9.4"(D) x 3.4"(H) x 7"(W) or 23.9 x 8.6 x 17.8 cm
B
Extension Jack
Maximum 2 devices per extension
jack, total REN on jack not to
exceed 2.0* (System phone
REN: 0.0 (zero))
No more than one system phone
per jack
4.5 lbs or 2.0 kgs
4.0 lbs or 1.8 kgs
10.5 lbs or 4.8 kgs
2.8 lbs or 1.3 kgs
2.8 lbs or 1.3 kgs
2.7 lbs or 1.2 kgs
2.7 lbs or 1.2 kgs
2.8 lbs or 1.3 kgs
Specifications B-1
