PSV7000 Operator's Manual

1Operation

This manual includes basic operation of the
PSV7000 System, but not functions deemed Admin-
istrator functions such as creating a job, teaching
Package Files, or creating a data file from a master
device.
PSV7000 is a programming and handling system for traditional and
fine-pitched integrated circuits (devices). It accepts most all package
types. The on-screen application that run PSV7000 is AH700.
Operator functions include installing some hardware, checking hard-
ware setup, turning on power, starting TaskLink (TL) or LumenX
Data Management Software (DMS), loading a job, and running a job.
Operators generally follow this sequence to process devices:
Install media, Install Socket
check options è Adapters
page 18 page 30
Set UI media Ensure
and options è Package File
page 54 was taught
Finishing...
Figure 1: Operator Functions. For a list of these steps see page 15.
Check probe
è tips / rotor è
tips, page 38
Start Pro-
è gramming
page 58
Finish or stop
è è
a Job
PSV7000
power up,
page 48
Resolving
Basic Errors
