Hint: Select a rotor tip
size that will work with
the largest selection of
your frequent target
devices.
PSV7000 Operator's Manual
■ Running a Job on PSV7000 ◘ List of Steps to Start a Job
5. Screw in the two new tips.
6. Rotate the Laser rotor by hand to access the other two tips.
Figure 29: The Laser rotor can be rotated by hand when the motor is
7. Remove and replace the second two tips.
8. Rotate the Laser rotor back to tips 1 and 2.
9. Close the safety door.
10. Re-enable the rotor motor at the RUN window by right-clicking
the Laser indicator (rectangle) and select submenu command
Access cups ready.
disabled (or the machine power is OFF).
