If You Have Trouble

Collecting System Logs

PSV7000 Operator's Manual
If programmer trouble occurs you should collect system log files.
Collect Logs is a software utility within AH700 Software that collects
all log files from the Data I/O Automated Programming System. It
creates a ZIP file containing all the information that Data I/O trained
service technicians need to evaluate your machine status.
There are several ways to start the Collect Logs utility:
If AH700 creates an error message on the monitor, it offers a Col-
lect Logs button.
In AH700, navigate to the System window and click Collect
Logs.
Click Windows Start button > [All Programs] > Dataio > Collect-
Logs.

Programmer Related Problems

When you experience a programmer related problem:
1.
Force the error to re-appear by running a job, or performing the
same steps that led to the trouble.
2.
Close all Data I/O software such as AH700, TaskLink/LumenX.
(Close AH700 the usual way: click Finish to stop a job, Exit the
Run Window, Exit the program.)
3.
Start Collect PSV7000 Logs by clicking the
windows Start button > Dataio > CollectLogs.
4.
(Optional) In Collect PSV7000 Logs, click Add Description.
5.
In Collect PSV7000 Logs, click Collect and ZIP and save the ZIP
file to a desired folder.
6.
To send to Data I/O Support,
6a. If your system doesn't have Internet connection, copy the
ZIP file to a USB Flash Drive.
6b. At the machine or a PC with Internet connection, open a
browser and navigate to www.Dataio.com and click Tech-
nical Support.
6c. Fill out the support for form, click Browse to locate the ZIP
file.
6d. Click Submit.
■ If You Have Trouble ◘ Collecting System Logs
—77—
