Operation ■ Changing Programmer Status

Changing Programmer Status

Disabling Programmers

The programmer status
Figure
menu is shown in
49 on page 69.
An optional method of
changing programmer
and socket status is with
the Programmer
Interface window.
(Setup window > Sys-
tem > Programmers)
See the on-screen Help
for more information.
—68—
PSV7000 may automatically disable a programmer for various rea-
sons, for example, if there are repeated continuity errors or vacuum
issues. The operator may also choose to disable a programmer, or
otherwise change the status of a programmer.
If programmers are not performing and the error cannot be cleared,
disable those programmers and continue to use the other sites to pro-
cess devices.
To disable a programmer:
1. At the Run window, click Pause.
2. Right-click on the target programmer and select All => DIS-
ABLED. All sockets on this programmer change to black and are
effectively disabled.
Note: To disable a single socket, right-click the socket and select
=> DISABLED. The socket changes to black and is disabled.
To resume a job click Run. When the job finishes, click Clear or manu-
ally remove any devices from the disabled programmer sockets.

Clearing a Disabled Status

If a programmer is disabled (the PNP head skips it) it may be
re-enabled if there are no devices in it as follows:
1. At the Run window, click Pause.
2. Right-click on the target programmer and select All => EMPTY.
This DOES NOT REMOVE DEVICES FROM THE SOCKETS,
only changes the status.
Note: To re-enable a single, empty socket, right-click the socket and
=> EMPTY.
select
This DOES NOT REMOVE DEVICES FROM THE SOCKET,
only changes the status.
All sockets on this programmer change to grey and are
re-enabled UNLESS THEY WERE NOT EMPTY.
3. To resume a job click Run.
Data I/O • 096-0461-001G
