Light Tower Interpretation

Light Condition
Red Operation
is stopped
due to major
error or
operator
action
Yellow/ Operation
Red is stopped
(alternating) due to error
or operator
action
Yellow Operation
is stopped
intention-
ally
Yellow/ Running
Green (alter- below opti-
nating) mum or
job is
ended
Green Running
normally
PSV7000 Operator's Manual
■ Light Tower Interpretation ◘ Stopping the System
During operation of the PSV7000 System, you can monitor the light
tower to reduce system down time. The light tower displays the fol-
lowing conditions:
Action Required
Operator intervention is
mandatory to continue.
It is likely that tools and
troubleshooting skills
will be required to
resolve issues.
Operator intervention is
mandatory to continue.
Correction may be
through Handler Com-
puter software (AH700)
or through minor hard-
ware adjustment.
Operator intervention is
mandatory.
Operator intervention is
suggested.
No operator action
needed.
Possible Causes
–Safety door or access door
is open
–E-Stop is pushed
–Actuator error
–Gantry collision
–Insufficient air pressure;
–Laser not ready
–Motion Control System
error
–Socket opener sensor
error
–Software exception
–Vacuum sensor malfunc-
tion
–File read/write error
–Labeler error
–Laser error
–No programmer can be
used
–PNP error
–Serialization errors
–Setup related errors
–Tape input error
–Unprogrammed devices
on Input/Pass tray
–Output media is full or
input media is empty.
–The main Start button has
been clicked (the Setup
window is displayed) but
no job is running.
–End of job
–Some sockets are disabled
–Vacuum errors are pres-
ent on some program-
mers
Processing devices, or clear-
ing sockets to output.
Machine
Status
Stopped
Stopped
Stopped
Processing or
Stopped (end
of job)
Processing
