Operation ■ Running a Job on PSV7000
2» Installing Input/Output Media
Regardless of input
media used, all should
proffer devices
right-side-up (live
bug orientation.
—18—
Some optional equipment needs to be set up or their settings checked
and power turned ON, or a process started. This is true even though
the equipment may have been installed by another individual such as
the administrator.
CAUTION: Electrostatic discharge (ESD) hazard! Wear an ESD
strap or discharge static against a common ground to prevent
damage to Socket Adapters and devices.
CAUTION: Safety hazard! Possible personal injury from moving
machinery. Always make sure that the PNP head is stopped in
the Park or Tool position before opening any access doors.
These input/output media are described in this section:
• Static Trays (next heading)
• Tube Input/Output (vibratory)
• Tape Feeder Input and Take up reel
• Tape Output
For Dual Tray Feeder input, see
If your job or work process uses other options such as a Barcode
Scanner, make sure they are installed and ready. Check with your
administrator or see the PSV7000 Owner's Manual.

Setting Up Static Trays

Static trays (no Tray Feeder) are installed using magnets to hold them
in place. The standard setup is described below, however many con-
figurations are possible.
Note: Make sure that the correct devices for the target job are
loaded into the input tray and that they have the correct pin 1 ori-
entation. (If pin 1 orientation doesn't match pin 1 that is set in the
Package File it must be corrected).
Pin 1 on Data I/O sockets is almost always toward the far side of
the Socket Adapter (the back of the machine).
Dual Tray Feeder on page 74.
Data I/O • 096-0461-001G
