PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included. If a part is missing, call 1-888-533-1333.
M8 x 30mm Washer
M4 x 16mm
M4 x 19mm
Screw
(93)–20
Screw (99)–2
M8 x 16mm
Screw (68)–2
M8 x 80mm Screw
M10 x 45mm Screw
M8 x 32mm Washer
(65)–2
M4 x 25mm
Flange
Screw
(95)–1
M8 x 18mm
Screw
(97)–2
(90)–2
(71)–4
M10 Washer
(64)–4
M5 x 10mm
M6 x 12mm
Screw
(100)–2
(92)–8
M8 x 72mm Screw
(72)–3
M10 x 20mm
Screw (74)–2
M10 x 68mm Screw
(86)–2
5
(91)–6
M8 x 14mm
Screw
Shoulder Screw
(73)–2
M10 x 20mm
Hex Screw (75)–2
