ASSEMBLY

• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you finish all assembly steps.
• Left parts are marked "L" or "Left" and right parts
are marked "R" or "Right."
• To identify small parts, see page 5.
1. Go to my.proform.com on your computer and
register your product.
• documents your ownership
• activates your warranty
• ensures priority customer support if assistance
is ever needed
Note: If you do not have internet access, call
1-888-533-1333 and register your product.
2. Place some of the packaging materials under the
front of the Frame (1). Have a second person
hold the Frame to prevent it from tipping.
Orient the Stabilizer (3) so that the sticker is
facing the Frame (1). Attach the Stabilizer to the
Frame with two M8 x 80mm Screws (90).
Then, remove the packaging materials from
beneath the Frame (1).
• In addition to the included tool(s), assembly
requires the following tools:
one Phillips screwdriver
two adjustable wrenches
Assembly may be easier if you have your own set
of wrenches. To avoid damaging parts, do not use
power tools.
1
2
6
90
3
1
