Item
Protocol
UDP/TCP port
Remote IP Address
Remote Subnet
Remote Subnet Mask
Redirect Gateway
Local Interface IP
Address
Remote Interface
IP Address
Ping Interval
Ping Timeout
Renegotiate Interval
Max Fragment Size
Compression
Continued from previous page
Description
Communication protocol:
UDP – OpenVPN will communicate using UDP
TCP server – OpenVPN will communicate using TCP in
server mode
TCP client – OpenVPN will communicate using TCP in
client mode
Port of the relevant protocol (UDP or TCP)
IP address of opposite tunnel side (domain name can be used)
IP address of a network behind opposite tunnel side
Subnet mask of a network behind opposite tunnel side
Allows to redirect all traffic on Ethernet
Defines the IP address of a local interface
Defines the IP address of the interface of opposite tunnel side
Defines the time interval after which sends a message to oppo-
site side of tunnel for checking the existence of the tunnel.
Defines the time interval during which the router waits for a mes-
sage sent by the opposite side. For proper verification of Open-
VPN tunnel, Ping Timeout must be greater than Ping Interval.
Sets renegotiate period (reauthorization) of the OpenVPN tun-
nel. This parameter can be set only when Authenticate Mode is
set to username/password or X.509 certificate. After this time
period, router changes the tunnel encryption to ensure the con-
tinues safety of the tunnel.
Defines the maximum size of a sent packet
Sent data can be compressed:
none – no compression is used
LZO – a lossless compression is used (must be set on both
sides of the tunnel!)
58
ER75s
Continued on next page
