8.13 NAT configuration
To enter the Network Address Translation configuration, select the NAT menu item. NAT
(Network address Translation / Port address Translation - PAT) is a method of adjusting the net-
work traffic through the router default transcript and/or destination IP addresses often change
the number of TCP/UDP port for walk-through IP packets. The window contains sixteen entries
for the definition of NAT rules.
Item
Public Port
Private Port
Type
Server IP address
If necessary set more than sixteen rules for NAT rules, then is possible insert into start up
script following script:
iptables -t nat -A napt -p tcp --dport [PORT\_PUBLIC] -j DNAT --to-destination
[IPADDR]:[PORT1\_PRIVATE]
Concrete IP address
are filled up into square bracket.
The following items are used to set the routing of all incoming traffic from the PPP to the
connected computer.
Item
Send all remaining incoming
packets to default server
Default Server IP Address
Table 35: Configuration of send all incoming packets
Description
Public port
Private port
Protocol selection
IP address which will be forwarded incoming data
Table 34: NAT configuration
and ports numbers
[IPADDR]
Description
By checking this item and setting the Default Server item
it is possible to put the router into the mode in which all
incoming data from GPRS will be routed to the computer
with the defined IP address.
Send all incoming packets to this IP addresses.
53
and
[PORT_PUBLIC] [PORT_PRIVATE]
ER75s
