Gas Fireplace
G800C
Installer: Please complete the details on the back cover and leave
this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
MODEL: G800C
Medium DV Gas Fireplace
www.regency-fire.com
01.06.20
