6.2 ADVANCED FUNCTIONS

This section describes software-dependent functions that can only be performed by Comfort User Interfaces
alongside the DM System. If your DM System will be controlled by a different User Interface, consult that
product's Operating Manual for instructions and safety advice.

6.2.1 FACTORY RESET

With this function, you can reset the DM System to its factory settings.
1. Press and hold the following Keys for 3 seconds:
1 2
▸ The display shows S and a number (e.g. S 4)
2. Press the DOWN Key until the display shows S 0.
▸ The display shows S 0.
SAVE
3. Press the SAVE Key.
▸ The DM System has now been reset to its factory settings. It is now in the
6.2.2 CONTAINER STOP AND SHELF STOP POSITIONS
These features can limit the movement area of the Table Top (if e.g. a container is below the table or a shelf
is above it). Container Stop Positions become the new lowest end position, Shelf Stop Positions the highest.
Container Stop Positions can only be saved only in the lower half of the movement
INFO
area, Shelf Stop Positions in the upper half. You must set each position separately.
Proceed as follows to save a Container Stop / Shelf Stop Position with a Comfort Handset:
1. Press the UP or DOWN Key to move the Table Top to the desired position
2. Press and hold the SAVE Key for 10 seconds
SAVE
▸ The Container Stop / Shelf Stop Position is saved
Proceed as follows to save a Container Stop / Shelf Stop Position with a Basic Handset:
3. Press and hold the UP Key and DOWN Key for 10 seconds.
▸ The Container Stop / Shelf Stop Position is saved
DYNAMIC MOTION SYSTEM - SYSTEM MANUAL // PAGE 22
• Memory Position Keys 1 and 2
• UP Key
same state as it was during the first start-up.
