Table with the Power Unit:
1. Plug the Actuators into the Power Unit
2. Plug the User Interface into the Power Unit
Other tables:
3. Plug the Actuators into the Benching Adapter
4. Plug the User Interface into the Benching Adapter
5. Plug the Benching Adapter into the Power Unit
6. If a Power Hub is used, plug the Power Hub into the Mains
INFO
A maximum of 4 tables (table 1 plus 3 others) can form a Benching System. For
Benching Systems with 3 or 4 tables, repeat steps 3 to 5 for each table.
4.3.3 COMPLETING ASSEMBLY
Before you use the table, you must perform a Position Reset Procedure (see Chapter 4.7 page 17).
