6 SOFTWARE-DEPENDENT
FUNCTIONS
6.1

STANDARD FUNCTIONS

This section describes the software-dependent functions that can be performed by Comfort and Basic User
Handsets alongside the DM System. If your DM System will be controlled by a different User Interface, con-
sult that product's Operating Manual for instructions and safety advice.
6.1.1

LOW SPEED AREA

During movement, this function causes a reduction in speed before the following positions are reached:
• Maximum and minimum Table Top height
• All saved positions (e.g. Memory Positions, Container Stop Position)
CAUTION Risk of minor or moderate injury through crushing
Collision Detection (ISP) is inactive in the Low Speed Area. This may lead to minor or
moderate injury through crushing.
• Ensure that no persons or objects are in the table's range of motion

6.1.2 SAFETY AREA

This function causes a safety stop at a defined Table Top height, which is set through the product's software.
INFO
You cannot save table positions that fall within the safety area.
CAUTION Risk of minor or moderate injury through crushing
Collision Detection (ISP) is inactive in the Safety Area. This may lead to minor or mod-
erate injury through crushing.
• Ensure that no persons or objects are in the table's range of motion
You can move the table into the safety area as follows:
1. Press and hold the DOWN Key
▸ The Table Top is adjusted to the start of the safety area
▸ The Table Top stops moving when the safety area is reached
2. Press the DOWN Key again to move into the safety area
DYNAMIC MOTION SYSTEM - SYSTEM MANUAL // PAGE 21
