7.3 REPLACING A POWER UNIT
1. Disconnect the Power Hub from the Mains
Power Hub
2. Disconnect all components from the Power Hub
3. Plug all components into the new Power Hub
4. Reconnect the system to the Mains
1. Disconnect all components from the Battery Pack
Battery Pack
2. Plug all components into the new Battery Pack

8 DISASSEMBLY

To disassemble the DM System, disconnect all connected devices from the Power Unit. Then, follow the as-
sembly instructions in reverse order.
9 COLLISION DETECTION
9.1

INTELLIGENT SYSTEM PROTECTION

Intelligent System Protection (ISP) is LOGICDATA's collision detection system. It significantly reduces the
risk system damage when using LOGICDATA products. If there is an obstacle in the operating range of a
table, and the obstacle and table collide, a load change affects the DM System. When the load change is
detected, all Actuators stop immediately and move back in the opposite direction for a few seconds (see 9.2
Drive Back Function). There are two types of ISP:
Software ISP uses known system variables that are measured or calculated by the soft-
ware within the system. Additional sensors are not necessary. This function is available
Software ISP
with all LOGICDATA Actuators (including those operated by external control boxes).
Sensor ISP Sensor ISP increases the sensitivity of the collision detection.

9.2 DRIVE BACK FUNCTION

After ISP is triggered, the Table Top automatically moves a defined distance in the opposite direction. This
reduces the risk of crushing.

10 MAINTENANCE

All products in the DM System are maintenance free for their entire service lifetimes.
CAUTION
This appliance can be used by children from 8 years and above and people with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning the use of the appliance in a safe
way and understand the hazards involved. Children must not play with the appliance.
Cleaning and maintenance by the user must not be performed by children, unless they
are over 8 years old and supervised.
DYNAMIC MOTION SYSTEM - SYSTEM MANUAL // PAGE 25
