4.1.2 Downward desktop movement

This function enables you to adjust the desktop downwards. To change its position,
proceed as follows:
Press the desktop down key.
Keep pressing the key until the required desktop height is reached.
Note: the desktop will continue moving downwards until you release the
key or the minimum height is reached.

4.2 Advanced functions

Note: you can only use the following functions of the COMPACT control
unit if you have a handswitch with memory position keys and a
memory key.

4.2.1 Saving a desktop position

This function allows you to save a defined desktop height .One desktop height can
be saved per memory position key. To save a position, proceed as follows:
Note: if you are switching on the COMPACT control unit for the first time,
all the saved positions are set to the lowest desktop height (minimum
desktop position).
1.
Adjust the desktop to the position you want to save.
The display will show the desktop height (e.g. 73cm).
2.
Press the memory key.
The display will read S –.
3.
Press the required memory position key (e.g. 2).
The display will read S 2.
4.
The set desktop position will now be saved to the selected memory
position key.
You will hear an audible double click and after about 2 seconds the
saved desktop position will be displayed.
Note: using saved desktop positions is only available for handswitches
with memory keys. The design of the memory position keys varies,
depending on the handswitch model used.
Page 17 / 43
