How to connect the system:
1. Plug the Actuators into the Power Unit for their respective Actuator Groups
2. Plug the User Interface(s) into the chosen Power Unit
3. Create a line of Power Units by connecting them to each other using the Sync Cable(s)
4. If Power Hubs are used, plug the Power Hubs into the Mains
INFO
The instructions describe assembly for a Table System with multiple Power Units
where 2 Actuators are plugged into each Power Unit. If you wish to connect more
Actuators to each Power Unit, you will require a special Branch Cable to accommo-
date the extra Cables. Contact LOGICDATA for more details.
4.4.3 COMPLETING ASSEMBLY
Before you use the table, you must perform a Position Reset Procedure (see Chapter 4.7 page 17).
DYNAMIC MOTION SYSTEM - SYSTEM MANUAL // PAGE 16
