DYNAMIC MOTION SYSTEM - SYSTEM MANUAL // PAGE 17

4.5 CONNECTING POWER HUBS

The DM System can be connected to the Mains via a Power Hub. The configuration of the Power Hub de-
pends on the type of Table System used. Read the assembly instructions for your Table System for more
details.

4.6 CONNECTING BATTERY PACKS

The DM System can be powered using a Battery Pack. For instructions and safety advice on mounting and
connecting Battery Packs, refer to your Battery Pack's Operating Manual.

4.7 PERFORMING A POSITION RESET PROCEDURE

CAUTION Risk of minor or moderate injury through crushing
Collision Detection (ISP) is inactive during start-up and reset processes. This may lead
to minor or moderate injury through crushing.
• Ensure that no persons or objects are in the table's range of motion
It is possible to perform a Position Reset Procedure with all types of compatible User Interface. However,
this section describes performing a Position Reset Procedure for Table Systems controlled by a Handset with
an UP Key and DOWN Key (Comfort or Basic Handsets).
If your DM System is operated by a different User Interface, consult that product's operating Manual for
instructions on performing a Position Reset Procedure.
1. Press and hold the DOWN Key until the table stops at the lower position limit
2. Release the DOWN Key
3. Press and hold the DOWN Key again
▸ The table will move down slightly, then up again
4. Release the DOWN Key
▸ The Position Reset Procedure is complete.
INFO
If your DM System has been parameterized with additional stopping points (e.g.
a Safety Area or Container Stop Position), repeat Step 3 until the table has moved
upwards again.
