6.2 REQUIRED COMPONENTS

1 HSU Hansdet
2 2 Mounting Screws (supplied by Reseller)
Tool Drill or Drilling Machine
Tool Screwdriver
Screw specifications
INFO
The mounting points for the HSU have a width of 5 mm. The Mounting Screws should
hold the Handset safely and securely in place. Exact specifications can be provided by
LOGICDATA on request.

6.3 PROCESS

1. Position the Handset under the table top and mark the position of the Mounting Points.
2. Drill the holes for the Mounting Screws into the Table Top at the marked points.
3. Use the screwdriver and 2 Mounting Screws to attach the Handset to the Table Top at the drilled
holes.
The required tightening torque depends on the material of the Table Top. Do not exceed
NOTICE
2 Nm.

6.4 COMPLETING ASSEMBLY

After the HSU is attached to the Table Top, you must connect the Cable to the Control Box. Refer to the man-
ual for your chosen Control Box for instructions.
HSU - MANUAL // PAGE 13
