Figure 3 - Refrigerant Flow-Thru Chiller (Falling Film Evaporator) - Johnson Controls YORK YK Style G OPTIVIEW Operation And Maintenance

FORM 160.75-O1 (211)
HOT GAS
BYPASS VALVE
DISCHARGE
OPTIONAL
ISOLATION
VALVE
CONDENSER
LIQUID LEVEL
SUB-COOLER
OPTIONAL
ISOLATION
VALVE

FIGURE 3 - REFRIGERANT FLOW-THRU CHILLER (FALLING FILM EVAPORATOR)

JOHNSON CONTROLS
SECTION 1 - DESCRIPTION OF SYSTEM AND FUNDAMENTALS OF OPERATION
Refrigerant Flow-Thru Chiller
YK Mod G
(Falling Film Evaporator)
Refrigerant Flow-Thru Cross-Section Diagram
(Falling-Film Evaporator)
COMPRESSOR
PRE-ROTATION
VANES
SUCTION
OPTIONAL HOT GAS
BYPASS LINE
LIQUID LEVEL
VALVE
EVAPORATOR
SUCTION
BAFFLE
LIQUID LEVEL
LD00924A
Rev. 2 (10-11-2010)
