Drop Leg (Enabled / Disabled)
Access Level Required: SERVICE
When a Drop Leg Refrigerant Sensor has been installed
it must be enabled via this toggle before the system
will utilize the new, enhanced resolution input.
Fault Acknowledge
(Software version C.MLM.01.11.xxx (and later) or
C.OPT.01.11.xxx (and later))
Access Level Required: SERVICE
This allows clearing of the High Condenser Pressure
Fault while Shutdown (Condenser-High Pressure
Stopped).
NAVIGATION
Home
Access Level Required: VIEW
Returns user to HOME Screen.
Refrigerant Level Control
Access Level Required: SERVICE
Moves to the subscreen allowing programming of the
refrigerant liquid level control setpoints.
JOHNSON CONTROLS
SECTION 2 - OPTIVIEW CONTROL CENTER INTRODUCTION
Heat Recovery
(Software version C.OPT.01.21.307 and later)
Access Level Required: SERVICE
Moves to a sub screen allowing programming and
viewing of the Heat Recovery setpoints and parame-
ters. Only appears when the Heat Recovery is enabled.
Head Pressure Control
(Software version C.OPT.01.21.307 and later)
Access Level Required: SERVICE
Moves to a sub screen allowing programming and
viewing of the Head Pressure Control setpoints and pa-
rameters. Only appears when Head Pressure Control is
enabled and Heat Recovery is disabled.
Heat Pump
(Software version C.OPT.01.23.307 and later)
Access Level Required: VIEW
Moves to a sub screen allowing programming and
viewing of the Heat Pump Setpoints and parameters.
Only appears when Heat Pump is enabled on the SET-
UP Screen.
