General Information
1-7

SPECIFICATIONS

Electrical Connections
Approvals
Power Requirements
Physical Dimensions
Weight
Operating Temperature
Surge Suppression
Humidity
Default BACnet/IP Address
Default BACnet MS/TP Address
("A Bank" DIP Switch Setting)
June 2012
Table 1-9. BACnet Interface Module Specifications
One 6‐pin Phoenix connector, one RS‐485 +/‐ ground port, power +/‐ frame ground port
One 3‐pin RS‐485 Phoenix connector, one RS‐485 +/‐ ground port
One Ethernet‐10/100 Ethernet port
BACnet Testing Laboratory (BTL) Marked
9 ‐ 30VDC or 12 ‐ 24VAC
4.5 in. L x 3.2 in.W x 1.6 in. H (11.5 cm L x 8.2 cm W x 4.0 cm H )
0.4 lbs (0.2 kg)
‐40°F to 167°F (‐40°C to 75°C)
EN61000‐4‐2 ESD EN61000‐4‐3 EMC EN61000‐4‐4 EFT
5 ‐ 90% RH (non‐condensing)
192.168.1.24
8
Note: Specifications are subject to change without notice.
1-12 P/N 06-237214-002
