8. You can now select additional Setup options to install (see step 3
above). When finished, click Exit.
9. The DataView folder now appears on your computer desktop, within
which is the Data Logger icon and the icon(s) for any other Control
Panel(s) you have installed.

5.2 Simple Logger II Control Panel

Clicking the DataView icon opens the core DataView program. Clicking
the Simple Logger II Control Panel icon opens the Simple Logger II
Control Panel.
In general, core DataView features are for creating, viewing, editing,
and storing DataView reports; while the Control Panel is for connecting
to, configuring, viewing real-time measurements, and downloading data
from the instrument. You can access all DataView features through either
the DataView icon or the Control Panel icon. For users who interact
with a single type of AEMC instrument, we recommend primarily using
the Control Panel. However, there are situations where using the core
DataView icon may be more convenient for some users, such as when
viewing multiple archived reports from different AEMC product families.
NOTE: For further information about DataView and its
capabilities, or for information about using the Simple
Logger II Control Panel, consult the Help system that
comes with the product. Access this Help by clicking the
option Help in the Control Panel's menu bar at the top of
the screen.
