AEMC Simple Logger II Series User Manual page 19

Find Quality Products Online at:
MODEL
ELECTRICAL
Channels
Input
Input Level
Maximum Input Voltage***
Input Impedance
Sample Rate
Storage Rate
Storage Mode
Recording Length
Memory
Communication
Power Source**
Battery Life
MECHANICAL
Dimensions
Weight (with battery)
Case
Vibration
Shock
Drop
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Relative Humidity
Altitude
SAFETY & ELECTRO-MAGNETIC COMPATIBILITY
Safety Rating
Protection Degree
CE Approved
(1) This recording mode stores the time and duration of the event, and the channel the event occurred on.
An event occurs when the input falls below 0.7V and ends when it rises above 0.8V. An internal pull up is
provided for contact closure.
18
GlobalTestSupply
www.
L404
Four
One 8-position removable screw-type terminal block
Contact closure, 0 to 5V
10V
DC
>150KW
Maximum of 8 per second
Maximum once every two sample periods (event dependent)
Event Recording
(1)
15 minutes to 8 weeks, programmable using DataView
50,000 events (512KB).
Recorded data is stored in non-volatile memory and
retained even if battery is low or removed.
USB 2.0 optically isolated
2x1.5V AA (LR6) alkaline batteries
100 hours to >45 days
(dependent on storage rate/recording length)
5.45 x 2.75 x 1.28" (136 x 70 x 32mm)
6.4 oz (181g)
Polycarbonate UL94-V0
IEC 68-2-6 (1.5mm, 10 to 55Hz)
IEC 68-2-27 (30G)
IEC 68-2-32 (1m)
14° to 122°F (-10° to 50°C)
-4° to 140°F (-20° to 60°C)
Up to 85% at 95°F (35°C), Non-condensing
6562' (2000m)
EN 61010-1; 50V CAT III; Pollution Degree 2
IP40
Yes
®
Simple Logger ® II Series
