MODEL
ELECTRICAL
Channels
Input
Range
Accuracy
(50/60Hz)
±(1% of Reading + 0.5A)
Resolution
Sample Rate
Storage Rate
Storage Modes
Start/Stop, FIFO and Extended Recording Mode* (XRM
Recording Length
Memory
Communication
Power Source**
Battery Life 100 hours to >45 days (dependent on storage rate/recording length)
MECHANICAL
Dimensions
Weight (with battery)
Sensor/Cable Length
Maximum Conductor Size
Case
Vibration
Shock
Drop
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Relative Humidity
Altitude
SAFETY & ELECTRO-MAGNETIC COMPATIBILITY
Safety Rating
Protection Degree
Electro-Magnetic
EN 61326-1; 07/1997 (+A1 10/1998, +A2 09/2001, +A3 05/2004)
Compatibility
CE Approved
24
GlobalTestSupply
www.
ML912
Two
Captive MiniFlex AC Current Flexible Sensors
®
0.5 to 100A
AC
0 to 1A unspecified
1 to 100A:
±(1% of Reading + 1A)
0.1A
64 samples/cycle
Programmable from 125ms to 1 day
15 minutes to 8 weeks, programmable using DataView
240,000 measurements (512 KB).
Recorded data is stored in non-volatile memory and retained
even if battery is low or removed.
USB 2.0 optically isolated
2x1.5V AA-cell alkaline batteries
4.95 x 2.75 x 1.28" (136 x 70 x 32mm) w/o Sensor
8.67 oz (245g)
Sensor: 6" (152mm) / Cable: 6 ft (2m)
Ø 1.77" (45mm)
UL94-V0
IEC 68-2-6 (1.5mm, 10 to 55Hz)
IEC 68-2-27 (30G)
IEC 68-2-32 (1m)
14° to 122°F (-10° to 50°C)
-4° to 140°F (-20° to 60°C)
Up to 85% at 95°F (35°C), Non-condensing
6562' (2000m)
EN61010-1; 600V CAT IV, 1000V CAT III; Pollution Degree 2
IP40
Yes
5 to 1000A
AC
0 to 5A unspecified
5 to 1000A:
), Alarm
™
®
