MODEL
ELECTRICAL
Channels
Input
Input Level
Accuracy
(50/60Hz)
Resolution
Maximum Input Current***
Sample Rate
Storage Rate
Storage Modes
Recording Length
Memory
240,000 measurement (512KB). Recorded data is stored in non-volatile
Communication
Power Source**
100 hours to > 45 days (dependent on sample rate/recording length)
Battery Life
MECHANICAL
Dimensions
Weight (with battery)
Case
Jaw Opening
1 conductor - Ø 1.42" (36mm); 2 conductors - Ø 1.00" (25mm) each
Vibration
Shock
Drop
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Relative Humidity
Altitude
SAFETY & ELECTRO-MAGNETIC COMPATIBILITY
Safety Rating
Protection Degree
Electro-Magnetic
EN 61326-1; 07/1997 (+A1 10/1998, +A2 09/2001, +A3 05/2004)
Compatibility
CE Approved
*This unique recording mode provides the opportunity to continuously record over long periods of time
by reducing the storage resolution of the stored data and maintaining matching resolution for the newest
data. Each time the memory fills up using XRM
making room for newer samples. This process continues until the recording is manually stopped.
**A memory backup capacitor provides backup power while the batteries are being changed. This
backup capacitor will maintain the instrument for up to 10 seconds without batteries installed. After 10
seconds the date and time will need to be reset (data and configuration will be maintained). If the unit is
connected to DataView ® via a PC, the battery life is 100 hours regardless of the storage rate.
*** Input level beyond this range may damage the instrument.
Specifications are subject to change without notice.
Simple Logger ® II Series
GlobalTestSupply
www.
CL601
One
Split CT – AC Current
0 to 600A
AC
0 to 5A: Unspecified
5 to 50A: ±(1% of Reading +1A)
50 to 400A: ±(1% of Reading +0.5A)
400 to 600A for duration <10min: ±(3% of Reading +1A)
0.1A
600A < 1 min
64 samples/cycle
Programmable from 125ms to 1 per day
Start/Stop, FIFO and Extended Recording Mode* (XRM
15 minutes to 8 weeks, programmable using DataView
memory and will be retained even if battery is low or removed.
USB 2.0 optically isolated
2x1.5V AA (LR6) alkaline batteries
9.25 x 4.0 x 1.63" (235 x 102 x 41mm)
17.1 oz (485g)
Polycarbonate UL94-V0
2 bus bars - 50 x 5mm
IEC 68-2-6 (1.5mm 10 to 55Hz)
IEC 68-2-27 (30G)
IEC 68-2-32 (1m)
14° to 122°F (-10° to 50°C)
-4° to 140°F (-20° to 60°C)
up to 85% at 95°F (35°C), Non-condensing
6562' (2000m)
EN 61010-2-032; 300V CAT IV, 600V CAT III; Pollution Degree 2
IP40
Yes
