AEMC Simple Logger II Series User Manual page 18

Find Quality Products Online at:
MODEL
ELECTRICAL
Channels
Input
Input Level
Accuracy
Resolution
Maximum Input Current***
Input Impedance
Sample Rate
Storage Rate
Storage Modes
Recording Length
Memory
Communication
Power Source**
Battery Life
MECHANICAL
Dimensions
Weight (with battery)
Case
Vibration
Shock
Drop
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Relative Humidity
Altitude
SAFETY & ELECTRO-MAGNETIC COMPATIBILITY
Safety Rating
Protection Degree
Electro-Magnetic
Compatibility
CE Approved
Simple Logger ® II Series
GlobalTestSupply
www.
L322
Two
One 4-position removable screw-type terminal block
-20mA to +20mA
DC
(0.25% of Reading +0.05mA)
0.01mA
±24mA
DC
50W
Maximum of 8 samples taken at storage interval
Programmable from 125ms to 1 per day
Start/Stop, FIFO and Extended Recording Mode* (XRM
15 minutes to 8 weeks, programmable using DataView
240,000 measurement (512KB).
Recorded data is stored in non-volatile memory and
retained even if battery is low or removed.
USB 2.0 optically isolated
2x1.5V AA (LR6) alkaline batteries
100 hours to >45 days
(dependent on storage rate/recording length)
5.45 x 2.75 x 1.28" (136 x 70 x 32mm)
6.4 oz (181g)
UL94-V0
IEC 68-2-6 (1.5mm, 10 to 55Hz)
IEC 68-2-27 (30G)
IEC 68-2-32 (1m)
14° to 122°F (-10° to 50°C)
-4° to 140°F (-20° to 60°C)
Up to 85% at 95°F (35°C), Non-condensing
6562' (2000m)
EN 61010-1; 50V CAT III; Pollution Degree 2
IP40
EN 61326-1; 07/1997 (+A1 10/1998, +A2 09/2001, +A3 05/2004)
Yes
.com
DC
™ ), Alarm
®
17
