The option Firmware Upgrades links to the website where you can
check for new firmware updates for the instrument. Finally, User Man-
uals displays a list of .pdf files contained in the USB drive that accom-
panies DataView. (DataView also comes with a Help system that is
installed with the program files.)
To install DataView, select DataView in the Options list and click Install.
4. Select the language version of DataView you want to install (Eng-
lish, French, or Spanish) then click Next. (By default, the language
selected in step 3 is highlighted.)
5. You are now prompted to select the software you want to install. Each
AEMC product family has its own specially designed Control Panel. If
you are performing a Complete install, by default all available Control
Panels are selected (a check mark next to the Control Panel indicates
it is selected). Control Panels take up disk space on the computer; so
unless you have other types of AEMC instruments, we recommend
that you select Data Logger and deselect the rest. You should also
check the option DataView Core, which is a requirement if you plan to
create DataView reports.
After you finish selecting and deselecting Control Panels and/or Data-
View Core, click Next.
6. The Setup program now informs you that it is ready to install Data-
View. If you want to review any of your previous selections, click the
Previous button to return to earlier screens. Otherwise, click Install to
begin installation.
7. The InstallShield program installs the selected software. If an
earlier version of the software is already installed on your com-
puter, for each selected program the InstallShield program will:
(a) Ask you to confirm the installation of the program. Click Next.
(b) Display a status bar indicating the progress of the installation.
(c) Inform you when the program is installed.
Click Finish to install the next selected program.
If the software is not installed (or if the installed software is the same
version as the selected software), the software is installed without
requesting confirmation.
When all programs are installed, a message appears informing you of
this. Click Finish to return to the Setup screen
