CHAPTER 2
USING BASIC FEATURES

Using the pens and erasers

The display comes with black, red, blue and green pens and
two erasers. You can use the pens to write and draw in digital
ink on the display, and you can use the erasers—or your palm
or fist—to erase digital ink.
There are magnetic holders for the pens and erasers at the
bottom of the display. Removing a pen from its holder
activates it. Return the pens and erasers to their holders when
you're done with them. Returning a pen to its holder charges it.
CAUTION
When you return a pen or eraser to its holder, make sure it's centered in the holder to keep it
from falling and being damaged. Pens' lights turn on to indicate that they're properly positioned
in their holders.

Pairing the pens with the display

After you install the display and turn it on for the first time, place the pens in the holders for at least
five minutes. This pairs the pens with the display and charges them for testing purposes.
IMPORTANT
Use only pens designed for SMART Board 7000R and 7000R Pro series interactive displays.
l
Pens for other SMART products, including SMART Board 7000 and 7000 Pro series
interactive displays, aren't compatible with SMART Board 7000R and 7000R Pro series
interactive displays (see smarttech.com/kb/171230).
If you previously paired a pen with a SMART Board 7000R or 7000R Pro series interactive
l
display, you must pair it with another display to use it with that display.
To fully charge the pens, keep them in the holders for at least four hours before you start
l
using the display.

Writing and drawing in digital ink

Up to four users can write or draw on the screen at the same time. Each pen writes and draws in its
own color. The Pen ID™ feature enables you to assign different colors, thicknesses, and other
properties to each pen.
