CHAPTER 1
WELCOME
NOTE
Unlike with older SMART Board interactive displays, you don't need to install an AM30, AM40, or
AM50 appliance in the accessory slot to use the iQ experience on SMART Board 7000R and
7000R series displays. The iQ experience is embedded on these displays (see iQ experience on
page 3). For this reason, SMART doesn't recommend installing AM30, AM40, or AM50 appliances
in these displays' accessory slots.

Convenience panel

Proximity sensors

mode.
For more information, see Waking up the display and putting it back to sleep on page 11.
5 smarttech.com/kb/171539
The convenience panel contains buttons for turning the display on
and off, controlling the volume, freezing and unfreezing the screen,
and showing and hiding a screen shade. It also includes connectors
for USB peripherals and a computer or other input source.
For more information about the convenience panel, see Using the
convenience panel on page 13.
The proximity sensors are located in the top-left and top-right corners
of the display's frame.
The proximity sensors can detect people up to 16' (5 m) away when
the display is in Standby mode.
When the proximity sensors detect people in the room, the display
either turns on or is ready to turn on, depending on how it's configured.
If the room is empty for 60 minutes, the display returns to Standby
