CHAPTER 2
USING BASIC FEATURES

Using the convenience panel

The convenience panel contains buttons for turning the display on and off, controlling the volume,
freezing and unfreezing the screen, and showing and hiding a screen shade. It also includes
connectors for USB peripherals and a computer or other input source.
No. Name
1 Power
2 Volume increase
3 Volume
decrease
4
Freeze
5
Screen shade
6 USB Type-A
receptacle (×2)
7 HDMI 4 input
source
connectors
8 USB Type-C input
source connector
13 smarttech.com/kb/171539
Procedure
Press to wake the display or put it back to sleep (see Waking
l
up the display and putting it back to sleep on page 11).
Press and hold for four seconds to turn off the display.
l
Press and hold for 10 seconds to reset the display.
l
Press to increase the volume (see Adjusting the volume on
page 21).
Press to decrease the volume (see Adjusting the volume on
page 21).
Press to freeze and unfreeze the screen (see page 21).
Press to hide screen contents behind a screen shade (see
Showing and hiding the screen shade on page 22).
Connect USB drives, peripherals, and other devices (see
Connecting USB drives, peripherals, and other devices on
page 37).
Connect a computer or other input source to use with the
display (see page 29).
Connect a computer or other input source to use with the
display (see page 29).
