Operation and Settings

6.
Use the SET button to specify the intensity for the illuminant that is being tested. If the intensity falls below the
specified range, the state of the switching output will change (from high to low, depending on the setting).
The sensitivity can be adjusted after completing a TEACH routine.
6.1
Fig. 3
1
2
3
4
5
6
7
colorCONTROL MFA-1
Operation and Settings

Control Panel

1 2 3
Control panel
Reduce sensitivity
Pick-up / drop-out delay
Timer -
Increase sensitivity
Light / dark switching
Timer + / enable
Teach button for setting thresholds
Function selection button
Switching state display
Contamination and alignment control
Timer ON
Button lock
7 6 5 4
