5.14

Interfaces

5.14.1 Connecting the RINT X11 robot interface/BUSINT X11 industrial bus interface

Damage due to the use of non-genuine parts!
The manufacturer's warranty becomes void if non-genuine parts are used!
•
Only use system components and options (power sources, welding torches, electrode
holders, remote controls, spare parts and replacement parts, etc.) from our range of
products!
•
Only insert and lock accessory components into the relevant connection socket when the
machine is switched off.
Damage due to incorrect connection!
Accessory components and the power source itself can be damaged by incorrect
connection!
•
Only insert and lock accessory components into the relevant connection socket when the
machine is switched off.
•
Comprehensive descriptions can be found in the operating instructions for the relevant
accessory components.
•
Accessory components are detected automatically after the power source is switched on.
The interfaces can be operated directly on the power source in a separate interface casing or externally,
e.g. in a robot control cabinet or via a data cable.

5.14.2 RINT X12 robot interface

The standard digital interface for mechanised applications
(optional, retrofitting on the machine or external fitting by the customer)
Functions and signals:
•
Digital inputs: start/stop, operating modes, JOB and program selection, inching, gas test
•
Analogue inputs: control voltages, e.g. for welding performance, welding current, etc.
•
Relay outputs: process signal, ready for welding, system composite fault, etc.

5.14.3 BUSINT X11 industrial bus interface

The solution for integration into mechanised production lines, with for example
•
Profibus
•
CAN-Open, CAN DeviceNet
•
Interbus systems with copper and optical fibre connection (FSMA/Rugged Line)
Only one variant can ever be operated at any one time.
099-005366-EW501
31.07.2014
CAUTION
NOTE
Design and function
Interfaces
39
