Design and function
Organising welding tasks (Mode "JOB Manager")

5.20.2 Loading an existing job

This function is used, for example, if the welding task (JOB) has been selected from the
JOB reference list (see Appendix).
Operating
element

5.20.3 Resetting an existing JOB to the factory setting (Reset JOB)

If a pre-programmed JOB (JOB 1 to 128) has been changed accidentally, it can be reset
to the factory settings.
Operating
element
68
Action Result
Select JOB Manager mode
3 x
Select JOB load function using the buttons
x x
"Up" and
Select the JOB to be loaded using the buttons
x x
"Up" and
JOB has been loaded
1 x
Machine returns to Display mode
3 x
Action Result
Select JOB Manager mode
3 x
Select the JOB reset function using the buttons
x x
"Up" and
Select the JOB (JOB 1-128) to be reset to the
x x
factory settings using the buttons
"Down" (right)
JOB has been reset
1 x
Machine returns to Display mode
1 x
NOTE
"Down" (left)
"Down" (right)
NOTE
"Down" (left)
"Up" and
Display
JOB Manager
Load JOB: xxx
Load JOB: xxx
Load JOB: xxx
Display
JOB Manager
Res. JOB: xxx
Res. JOB: xxx
Res. JOB: xxx
