5.16.7 MIG/MAG program sequence ("Program steps" mode)

Certain materials, such as aluminium, require special functions in order to be able to weld them safely
and at high quality. The non-latched special operating mode is used here with the following programs:
•
Start program P
•
Main program P
•
Reduced main program P
•
End program P

5.16.8 Selection

Operating
element

5.16.9 MIG/MAG overview of parameters for M3.1x

099-005366-EW501
31.07.2014
(reduction of cool points at the start of the seam)
START
(continuous welding)
A
(targeted heat reduction)
B
(minimisation of end craters via targeted heat reduction)
END
Action Result
Select program sequence mode
1 x
Select the parameters using the buttons
n x
and "Down" (left)
Adjust the selected parameter using the buttons
n x
"Up" and
Machine returns to display mode
3 x
Design and function
Definition of MIG/MAG welding tasks
"Down" (right)
Figure 5-26
Display
Program steps
"Up"
