Design and function

"Job Info" mode

5.18 "JOB Info" mode
Information on the current JOB is displayed in this mode.
•
In JOBs 127 and 128 (TIG & MMA), it is not possible to select the mode as it would not be
relevant.
Selection:
Operating
element
JOB Info parameter list:
Parameter (display)
Uist
System
JOB-Typ
JOB-Nr.
akt. Prg.
Mode
Schweiss
JOB-Text
Wire
Material
Gas-Typ
Verf.
5.19

Operating time counter

The operating time is displayed in the format hhhh:mm:'h'. Four digits for the hours, two digits for the
minute, and a final 'h' symbol.
On the welding machine control
Operating element
The operating time is counted when current is flowing, and is written to non-volatile memory once per
minute.
66
Action Result
Select "JOB Info mode"
n x
Parameter selection
Explanation
Voltage
System status
Pre-defined or user-defined JOB
JOB number
Program number
Operating mode
Welding type
Text information relating to the JOB (can be edited using PC 300.Net
software)
Wire diameter
Material type
Gas type
Welding process
Action Result
Press until signal light
n x
NOTE
comes on
Display
JOB Info
See "JOB Info" parameter list
table
Display
Operating time
display
